Medical & Cold Chain Cases

Transporting medical devices, emergency supplies and biological samples demands both physical protection and temperature control. The kexinMaterials medical case range spans first-aid cases, vaccine cold boxes and specimen carriers, built with medical-grade liners and insulated structures for hospitals, CDCs and pharma logistics.

Reliability in a medical case comes from structure: kexinMaterials combines PU-foamed insulation walls with sealed shells and dedicated ice-pack bays, holding 2–8°C for 48+ hours under standard load (model and ambient dependent), with mounting points for temperature data loggers.

For device manufacturers and pharma distributors, kexinMaterials offers OEM programs on the medical case: custom inserts sized to your device, insulation test data for cold-chain validation, and logger accessories for GDP/GSP compliance — one supplier from registration to operations.

Key facts: The Medical & Cold Chain Cases is manufactured factory-direct by KeXin New Materials (Guangdong) Co., Ltd. (brand: kexinMaterials): IP67 options, MOQ 50 pcs on stock models, samples in 7–15 days, production in 15–30 days, exporting to 8 major markets.

Series Capabilities

PU foam insulation holding 2–8°C with ice packs

Medical/food-grade liners, easy to disinfect

Mounting bays for temperature data loggers

Modular layered interiors for triage organization

IP67 sealed shell against rain, dust, contamination

Cold-chain validation data and OEM support

Engineering Details

Sealing, interior and latching are the three structures that decide real-world protection.

**IP67 sealing system**A silicone gasket seated in the lid channel deforms under compression latches to fill the mating gap — no ingress at 1 m for 30 minutes.

**CNC-cut EVA interior**Machined from your equipment's 3D data with a 20–30 mm cushion to the shell, and no permanent compression set over years of use.

**Latches & hinges**Compression latches maintain constant sealing force and accept padlock hasps, combination locks or lead seals. Both latches and hinges are field-replaceable wear parts.

Key Specifications

Shell material	Modified PP / PE with PU foam insulation
Temperature hold	2–8°C / 15–25°C with ice packs (validated per model)
Protection rating	IP67
Liner	Food-grade EVA / medical PE, disinfectable
Monitoring	Logger bay, humidity indicator options
Compliance	GDP/GSP cold-chain validation support

Typical Applications

Vaccine and biologics cold-chain delivery

Ambulance and pre-hospital emergency kits

Inter-lab biological specimen transfer

Clinical trial material logistics

Disaster medical relief pre-positioning

Corporate and household first-aid storage

Frequently Asked Questions

How long can 2–8°C be maintained?

Depends on model, ice-pack setup and ambient: standard setups hold 48+ hours at 35°C ambient. We provide measured curves for your actual load profile.

Can a data logger be installed?

Yes — a fixed logger bay inside plus an external-read window option, compatible with mainstream USB and Bluetooth loggers.

What disinfection do liners tolerate?

Food-grade EVA and medical PE liners tolerate 75% alcohol and chlorine-based wipes, and lift out for full washing.

Can you support our GDP/GSP validation?

Yes — insulation test data, loading recommendations and validation templates to complete your transport qualification files.

Can first-aid interiors be configured per department?

Yes. Modular trays are arranged to your supply checklist, with department marking and numbering options.

Can medical cases be wiped with disinfectant?

Yes. The modified PP/ABS shell tolerates 75% alcohol, chlorine-based and quaternary ammonium disinfectant wipes; avoid prolonged soaking in strong oxidizers. Inserts can be specified as removable, washable EVA or medical-grade foam for routine cleaning.

Can you build cold-chain or insulated versions?

Yes. We offer PU-foam insulated shells that hold 2–8 °C or -20 °C ranges for short-haul transport when combined with ice packs or phase-change coolant. A mounting pocket and read-out window for a temperature logger can be pre-installed.

Can the interior be zoned by clinical function?

Yes. A common layout separates resuscitation, airway, trauma and pharmacy items with color-coded bands and clear elastic pockets so contents are visible and restocking is orderly. Layouts can be rebuilt around your hospital's protocol, with a checklist printed inside the lid.

Can the case be mounted in an ambulance?

Yes. We supply versions with mounting bases or clips that mate with stretcher frames and cabin wall fixings so the case cannot shift in transit, plus anti-slip feet and quick-release straps for carrying once on scene.

What compliance requirements apply to medical transport cases?

In China, storage and transport conditions, temperature/humidity records and cleaning are governed by medical device distribution quality rules; exports follow the destination country's registration requirements. As an accessory, the case ships with material safety notes and cleaning validation guidance to support your documentation.

Can it be made lighter for single-person carry?

Yes. Optimizing wall-thickness distribution, using high-flow modified resins and honeycomb ribbing cuts 15–25% of weight while keeping strength, combined with ergonomic handles and a shoulder strap for longer one-person carries.
